flat roller bearings
Flat roller bearings are composed of a needle roller integrated into a flat cage. It is a compact linear guide device that can carry high loads and is suitable for machine tools that have high requirements for positioning accuracy, repeatability and rigidity.
Models
Single Row
Double Row
Single Row
| Model No. | |||
| b | l | Da | |
| mm | mm | mm | |
| FT 2010-32 | 10 | 32 | 2 |
| FT 2515-45 | 15 | 45 | 2.5 |
| FT 3020-60 | 20 | 60 | 3 |
| FT 3525-75 | 25 | 75 | 3.5 |
| FT 4030-150 | 30 | 150 | 4 |
| FT 4035-150 | 35 | 150 | 4 |
| FT 5038-250 | 38 | 250 | 5 |
| FT 5043-250 | 43 | 250 | 5 |
| FT 10054-400 | 54 | 400 | 10 |
| FT 10080-500 | 80 | 500 | 10 |
Double Row
| Model No. | b | b1 | 1 | D, | B |
| FTW 4030V-150 | 30 | 24.5 | 150 | 2.828 | 22.8 |
| FTW 5045-250 | 45 | 35.5 | 250 | 5 | 32.8 |
| FTW 5050-250 | 50 | 40.5 | 250 | 5 | 37.8 |
| FTW 5035V-250 | 35 | 29 | 250 | 3.535 | 26.8 |
| FTW 6022.4-320 | 22.4 | 14.4 | 320 | 6 | 12.8 |
| FTW 10036V-380 | 36 | 26.6 | 380 | 7.071 | 25 |
| FTW 10043.5V-380 | 43.5 | 34 | 380 | 7.071 | 31.8 |
| FTW 10070V-500 | 70 | 56.5 | 500 | 7.071 | 52.8 |
