angular contact ball bearings
Angular Contact Ball Bearings have raceways on the inner and outer rings, and the inner and outer rings can be relatively displaced along the bearing axis.An axial load passes in a straight line through the bearing, whereas a radial load takes an oblique path that acts to separate the races axially.
Models Of angular contact ball bearings
Single Row
Double Row
Four-point Angular Contact Series
Precision Series for Machine Tools
Symbol Explanation
Single Row
Single-row angular contact ball bearings handle thrust loads on one side. For applications with thrust loads on both sides, mount them in pairs.
7000,7200,7300,7400,7900 series
| Part Number | Contact Angle (Degree) | Bore Dia (d) | Outer Dia (D) | Width (B) |
| 7900A5TYN | 25 | 10 mm | 22 mm | 6 mm |
| 7900CTYN | 15 | 10 mm | 22 mm | 6 mm |
| 7000AW | 30 | 10 mm | 26 mm | 8 mm |
| 7000CTYN | 15 | 10 mm | 26 mm | 8 mm |
| 7200AW | 30 | 10 mm | 30 mm | 9 mm |
| 7200BW | 40 | 10 mm | 30 mm | 9 mm |
| 7200CTYN | 15 | 10 mm | 30 mm | 9 mm |
| 7300AW | 30 | 10 mm | 35 mm | 11 mm |
| 7300BW | 40 | 10 mm | 35 mm | 11 mm |
| 7901A5TYN | 25 | 12 mm | 24 mm | 6 mm |
| 7901CTYN | 15 | 12 mm | 24 mm | 6 mm |
| 7001AW | 30 | 12 mm | 28 mm | 8 mm |
| 7001CTYN | 15 | 12 mm | 28 mm | 8 mm |
| 7201AW | 30 | 12 mm | 32 mm | 10 mm |
| 7201BEAT85 | 40 | 12 mm | 32 mm | 10 mm |
| 7201BW | 40 | 12 mm | 32 mm | 10 mm |
| 7201CTYN | 15 | 12 mm | 32 mm | 10 mm |
| 7301AW | 30 | 12 mm | 37 mm | 12 mm |
| 7301BEAT85 | 40 | 12 mm | 37 mm | 12 mm |
| 7301BW | 40 | 12 mm | 37 mm | 12 mm |
| 7902A5TYN | 25 | 15 mm | 28 mm | 7 mm |
| 7902CTYN | 15 | 15 mm | 28 mm | 7 mm |
| 7002CTYN | 15 | 15 mm | 32 mm | 9 mm |
| 7002AW | 30 | 15 mm | 32 mm | 9 mm |
| 7202AW | 30 | 15 mm | 35 mm | 11 mm |
| 7202BEAT85 | 40 | 15 mm | 35 mm | 11 mm |
| 7202BW | 40 | 15 mm | 35 mm | 11 mm |
| 7202CTYN | 15 | 15 mm | 35 mm | 11 mm |
| 7302AW | 30 | 15 mm | 42 mm | 13 mm |
| 7302BEAT85 | 40 | 15 mm | 42 mm | 13 mm |
| 7302BW | 40 | 15 mm | 42 mm | 13 mm |
| 7903A5TYN | 25 | 17 mm | 30 mm | 7 mm |
| 7903CTYN | 15 | 17 mm | 30 mm | 7 mm |
| 7003AW | 30 | 17 mm | 35 mm | 10 mm |
| 7003CTYN | 15 | 17 mm | 35 mm | 10 mm |
| 7203AW | 30 | 17 mm | 40 mm | 12 mm |
| 7203BEAT85 | 40 | 17 mm | 40 mm | 12 mm |
| 7203BW | 40 | 17 mm | 40 mm | 12 mm |
| 7203CTYN | 15 | 17 mm | 40 mm | 12 mm |
| 7303AW | 30 | 17 mm | 47 mm | 14 mm |
| 7303BEAT85 | 40 | 17 mm | 47 mm | 14 mm |
| 7303BW | 40 | 17 mm | 47 mm | 14 mm |
| 7904A5TYN | 25 | 20 mm | 37 mm | 9 mm |
| 7904CTYN | 15 | 20 mm | 37 mm | 9 mm |
| 7004AW | 30 | 20 mm | 42 mm | 12 mm |
| 7004CTYN | 15 | 20 mm | 42 mm | 12 mm |
| 7204BEAT85 | 40 | 20 mm | 47 mm | 14 mm |
| 7204AW | 30 | 20 mm | 47 mm | 14 mm |
| 7204BW | 40 | 20 mm | 47 mm | 14 mm |
| 7204CTYN | 15 | 20 mm | 47 mm | 14 mm |
| 7304AW | 30 | 20 mm | 52 mm | 15 mm |
| 7304BEAT85 | 40 | 20 mm | 52 mm | 15 mm |
| 7304BW | 40 | 20 mm | 52 mm | 15 mm |
| 7905A5TYN | 25 | 25 mm | 42 mm | 9 mm |
| 7905CTYN | 15 | 25 mm | 42 mm | 9 mm |
| 7005AW | 30 | 25 mm | 47 mm | 12 mm |
| 7005CTYN | 15 | 25 mm | 47 mm | 12 mm |
| 7205AW | 30 | 25 mm | 52 mm | 15 mm |
| 7205BEAT85 | 40 | 25 mm | 52 mm | 15 mm |
| 7205BW | 40 | 25 mm | 52 mm | 15 mm |
| 7205CTYN | 15 | 25 mm | 52 mm | 15 mm |
| 7305AW | 30 | 25 mm | 62 mm | 17 mm |
| 7305BEAT85 | 40 | 25 mm | 62 mm | 17 mm |
| 7305BW | 40 | 25 mm | 62 mm | 17 mm |
| 7906A5TYN | 25 | 30 mm | 47 mm | 9 mm |
| 7906CTYN | 15 | 30 mm | 47 mm | 9 mm |
| 7006AW | 30 | 30 mm | 55 mm | 13 mm |
| 7006CTYN | 15 | 30 mm | 55 mm | 13 mm |
| 7206AW | 30 | 30 mm | 62 mm | 16 mm |
| 7206BEAT85 | 40 | 30 mm | 62 mm | 16 mm |
| 7206BW | 40 | 30 mm | 62 mm | 16 mm |
| 7206CTYN | 15 | 30 mm | 62 mm | 16 mm |
| 7306AW | 30 | 30 mm | 72 mm | 19 mm |
| 7306BW | 40 | 30 mm | 72 mm | 19 mm |
| 7306BEAT85 | 40 | 30 mm | 72 mm | 19 mm |
| 7907A5TYN | 25 | 35 mm | 55 mm | 10 mm |
| 7907CTYN | 15 | 35 mm | 55 mm | 10 mm |
| 7007AW | 30 | 35 mm | 62 mm | 14 mm |
| 7007CTYN | 15 | 35 mm | 62 mm | 14 mm |
| 7207AW | 30 | 35 mm | 72 mm | 17 mm |
| 7207BEAT85 | 40 | 35 mm | 72 mm | 17 mm |
| 7207BW | 40 | 35 mm | 72 mm | 17 mm |
| 7307BW | 40 | 35 mm | 80 mm | 21 mm |
| 7307BEAW | 40 | 35 mm | 80 mm | 21 mm |
| 7307BEAT85 | 40 | 35 mm | 80 mm | 21 mm |
| 7307AW | 30 | 35 mm | 80 mm | 21 mm |
| 7207C | 15 | 35 mm | 72 mm | 17 mm |
| 7008AW | 30 | 40 mm | 68 mm | 15 mm |
| 7908CTYN | 15 | 40 mm | 62 mm | 12 mm |
| 7908A5TYN | 25 | 40 mm | 62 mm | 12 mm |
| 7008C | 15 | 40 mm | 68 mm | 15 mm |
| 7208AW | 30 | 40 mm | 80 mm | 18 mm |
| 7208BEAT85 | 40 | 40 mm | 80 mm | 18 mm |
| 7208BW | 40 | 40 mm | 80 mm | 18 mm |
| 7208C | 15 | 40 mm | 80 mm | 18 mm |
| 7308AW | 30 | 40 mm | 90 mm | 23 mm |
| 7308BEAT85 | 40 | 40 mm | 90 mm | 23 mm |
| 7308BEAW | 40 | 40 mm | 90 mm | 23 mm |
| 7308BW | 40 | 40 mm | 90 mm | 23 mm |
| 7909A5 | 25 | 45 mm | 68 mm | 12 mm |
| 7909C | 15 | 45 mm | 68 mm | 12 mm |
| 7009AW | 30 | 45 mm | 75 mm | 16 mm |
| 7009C | 15 | 45 mm | 75 mm | 16 mm |
| 7209AW | 30 | 45 mm | 85 mm | 85 mm |
| 7209BEAT85 | 40 | 45 mm | 85 mm | 19 mm |
| 7209BW | 40 | 45 mm | 85 mm | 19 mm |
| 7209C | 15 | 45 mm | 85 mm | 19 mm |
| 7309AW | 30 | 45 mm | 100 mm | 25 mm |
| 7309BEAT85 | 40 | 45 mm | 100 mm | 25 mm |
| 7309BEAW | 40 | 45 mm | 100 mm | 25 mm |
| 7309BW | 40 | 45 mm | 100 mm | 25 mm |
| 7910A5 | 25 | 50 mm | 72 mm | 12 mm |
| 7910C | 15 | 50 mm | 72 mm | 12 mm |
| 7010AW | 30 | 50 mm | 80 mm | 16 mm |
| 7010C | 15 | 50 mm | 80 mm | 16 mm |
| 7210AW | 30 | 50 mm | 90 mm | 20 mm |
| 7210BEAT85 | 40 | 50 mm | 90 mm | 20 mm |
| 7210BW | 40 | 50 mm | 90 mm | 20 mm |
| 7210C | 15 | 50 mm | 90 mm | 20 mm |
| 7310AW | 30 | 50 mm | 110 mm | 27 mm |
| 7310BEAT85 | 40 | 50 mm | 110 mm | 27 mm |
| 7310BEAW | 40 | 50 mm | 110 mm | 27 mm |
| 7310BW | 40 | 50 mm | 110 mm | 27 mm |
| 7911A5 | 25 | 55 mm | 80 mm | 13 mm |
| 7911C | 15 | 55 mm | 80 mm | 13 mm |
| 7011AW | 30 | 55 mm | 90 mm | 18 mm |
| 7011C | 15 | 55 mm | 90 mm | 18 mm |
| 7211AW | 30 | 55 mm | 100 mm | 21 mm |
| 7211BEAT85 | 40 | 55 mm | 100 mm | 21 mm |
| 7211BW | 40 | 55 mm | 100 mm | 21 mm |
| 7211C | 15 | 55 mm | 100 mm | 21 mm |
| 7311AW | 30 | 55 mm | 120 mm | 29 mm |
| 7311BEAT85 | 40 | 55 mm | 120 mm | 29 mm |
| 7311BEAW | 40 | 55 mm | 120 mm | 29 mm |
| 7311BW | 40 | 55 mm | 120 mm | 29 mm |
| 7912A5 | 25 | 60 mm | 85 mm | 13 mm |
| 7912C | 15 | 60 mm | 85 mm | 13 mm |
| 7012AW | 30 | 60 mm | 95 mm | 18 mm |
| 7012C | 15 | 60 mm | 95 mm | 18 mm |
| 7212AW | 30 | 60 mm | 110 mm | 22 mm |
| 7212BEAT85 | 40 | 60 mm | 110 mm | 22 mm |
| 7212BW | 40 | 60 mm | 110 mm | 22 mm |
| 7212C | 15 | 60 mm | 110 mm | 22 mm |
| 7312AW | 30 | 60 mm | 130 mm | 31 mm |
| 7312BEAT85 | 40 | 60 mm | 130 mm | 31 mm |
| 7312BEAW | 40 | 60 mm | 130 mm | 31 mm |
| 7913C | 15 | 65 mm | 90 mm | 13 mm |
| 7913A5 | 25 | 65 mm | 90 mm | 13 mm |
| 7013AW | 30 | 65 mm | 100 mm | 18 mm |
| 7013C | 15 | 65 mm | 100 mm | 18 mm |
| 7213AW | 30 | 65 mm | 120 mm | 23 mm |
| 7213BEAT85 | 40 | 65 mm | 120 mm | 23 mm |
| 7213BW | 40 | 65 mm | 120 mm | 23 mm |
| 7213C | 15 | 65 mm | 120 mm | 23 mm |
| 7313AW | 30 | 65 mm | 140 mm | 33 mm |
| 7313BEAT85 | 40 | 65 mm | 140 mm | 33 mm |
| 7313BEAW | 40 | 65 mm | 140 mm | 33 mm |
| 7914A5 | 25 | 70 mm | 100 mm | 16 mm |
| 7914C | 15 | 70 mm | 100 mm | 16 mm |
| 7014AW | 30 | 70 mm | 110 mm | 20 mm |
| 7014C | 15 | 70 mm | 110 mm | 20 mm |
| 7214AW | 30 | 70 mm | 125 mm | 24 mm |
| 7214BEAT85 | 40 | 70 mm | 125 mm | 24 mm |
| 7214BW | 40 | 70 mm | 125 mm | 24 mm |
| 7214C | 15 | 70 mm | 125 mm | 24 mm |
| 7314AW | 30 | 70 mm | 150 mm | 35 mm |
| 7314BEAT85 | 40 | 70 mm | 150 mm | 35 mm |
| 7314BEAW | 40 | 70 mm | 150 mm | 35 mm |
| 7915A5 | 25 | 75 mm | 105 mm | 16 mm |
| 7915C | 15 | 75 mm | 105 mm | 16 mm |
| 7015AW | 30 | 75 mm | 115 mm | 20 mm |
| 7015C | 15 | 75 mm | 115 mm | 20 mm |
| 7215AW | 30 | 75 mm | 130 mm | 25 mm |
| 7215BEAT85 | 40 | 75 mm | 130 mm | 25 mm |
| 7215BW | 40 | 75 mm | 130 mm | 25 mm |
| 7215C | 15 | 75 mm | 130 mm | 25 mm |
| 7315AW | 30 | 75 mm | 160 mm | 37 mm |
| 7315BEAT85 | 40 | 75 mm | 160 mm | 37 mm |
| 7315BEAW | 40 | 75 mm | 160 mm | 37 mm |
| 7916A5 | 25 | 80 mm | 110 mm | 16 mm |
| 7916C | 15 | 80 mm | 110 mm | 16 mm |
| 7016AW | 30 | 80 mm | 125 mm | 22 mm |
| 7016C | 15 | 80 mm | 125 mm | 22 mm |
| 7216AW | 30 | 80 mm | 140 mm | 26 mm |
| 7216BEAT85 | 40 | 80 mm | 140 mm | 26 mm |
| 7216BW | 40 | 80 mm | 140 mm | 26 mm |
| 7216C | 15 | 80 mm | 140 mm | 26 mm |
| 7316AW | 30 | 80 mm | 170 mm | 39 mm |
| 7316BEAT85 | 40 | 80 mm | 170 mm | 39 mm |
| 7316BEAW | 40 | 80 mm | 170 mm | 39 mm |
| 7917A5 | 25 | 85 mm | 120 mm | 18 mm |
| 7917C | 15 | 85 mm | 120 mm | 18 mm |
| 7017AW | 30 | 85 mm | 130 mm | 22 mm |
| 7017C | 15 | 85 mm | 130 mm | 22 mm |
| 7217AW | 30 | 85 mm | 150 mm | 28 mm |
| 7217BEAT85 | 40 | 85 mm | 150 mm | 28 mm |
| 7217BW | 40 | 85 mm | 150 mm | 28 mm |
| 7217C | 15 | 85 mm | 150 mm | 28 mm |
| 7317AW | 30 | 85 mm | 180 mm | 41 mm |
| 7317BEAT85 | 40 | 85 mm | 180 mm | 41 mm |
| 7317BW | 40 | 85 mm | 180 mm | 41 mm |
| 7918A5 | 25 | 90 mm | 125 mm | 18 mm |
| 7918C | 15 | 90 mm | 125 mm | 18 mm |
| 7018AW | 30 | 90 mm | 140 mm | 24 mm |
| 7018C | 15 | 90 mm | 140 mm | 24 mm |
| 7218AW | 30 | 90 mm | 160 mm | 30 mm |
| 7218BEAT85 | 40 | 90 mm | 160 mm | 30 mm |
| 7218BW | 40 | 90 mm | 160 mm | 30 mm |
| 7218C | 15 | 90 mm | 160 mm | 30 mm |
| 7318AW | 30 | 90 mm | 190 mm | 43 mm |
| 7318BEAT85 | 40 | 90 mm | 190 mm | 43 mm |
| 7318BW | 40 | 90 mm | 190 mm | 43 mm |
| 7919A5 | 25 | 95 mm | 130 mm | 18 mm |
| 7219AW | 30 | 95 mm | 170 mm | 32 mm |
| 7919C | 15 | 95 mm | 130 mm | 18 mm |
| 7019A | 30 | 95 mm | 145 mm | 24 mm |
| 7019C | 15 | 95 mm | 145 mm | 24 mm |
| 7219BEAT85 | 40 | 95 mm | 170 mm | 32 mm |
| 7219BW | 40 | 95 mm | 170 mm | 32 mm |
| 7219C | 15 | 95 mm | 170 mm | 32 mm |
| 7319BEAT85 | 40 | 95 mm | 200 mm | 45 mm |
| 7319AW | 30 | 95 mm | 200 mm | 45 mm |
| 7319BW | 40 | 95 mm | 200 mm | 45 mm |
| 7920A5 | 25 | 100 mm | 140 mm | 20 mm |
| 7920C | 15 | 100 mm | 140 mm | 20 mm |
| 7020A | 30 | 100 mm | 150 mm | 24 mm |
| 7020C | 15 | 100 mm | 150 mm | 24 mm |
| 7220AW | 30 | 100 mm | 180 mm | 34 mm |
| 7220BEAT85 | 40 | 100 mm | 180 mm | 34 mm |
| 7220BW | 40 | 100 mm | 180 mm | 34 mm |
| 7220C | 15 | 100 mm | 180 mm | 34 mm |
| 7320AW | 30 | 100 mm | 215 mm | 47 mm |
| 7320BEAT85 | 40 | 100 mm | 215 mm | 47 mm |
| 7320BW | 40 | 100 mm | 215 mm | 47 mm |
| 7921A5 | 25 | 105 mm | 145 mm | 20 mm |
| 7921C | 15 | 105 mm | 145 mm | 20 mm |
| 7021A | 30 | 105 mm | 160 mm | 26 mm |
| 7021C | 15 | 105 mm | 160 mm | 26 mm |
| 7221AW | 30 | 105 mm | 190 mm | 36 mm |
| 7221BEAT85 | 40 | 105 mm | 190 mm | 36 mm |
| 7221BW | 40 | 105 mm | 190 mm | 36 mm |
| 7221C | 15 | 105 mm | 190 mm | 36 mm |
| 7321A | 30 | 105 mm | 225 mm | 49 mm |
| 7321B | 40 | 105 mm | 225 mm | 49 mm |
| 7321BEAT85 | 40 | 105 mm | 225 mm | 49 mm |
| 7922A5 | 25 | 110 mm | 150 mm | 20 mm |
| 7922C | 15 | 110 mm | 150 mm | 20 mm |
| 7022A | 30 | 110 mm | 170 mm | 28 mm |
| 7022C | 15 | 110 mm | 170 mm | 28 mm |
| 7222AW | 30 | 110 mm | 200 mm | 38 mm |
| 7222BEAT85 | 40 | 110 mm | 200 mm | 38 mm |
| 7222BW | 40 | 110 mm | 200 mm | 38 mm |
| 7222C | 15 | 110 mm | 200 mm | 38 mm |
| 7322A | 30 | 110 mm | 240 mm | 50 mm |
| 7322B | 40 | 110 mm | 240 mm | 50 mm |
| 7322BEAT85 | 40 | 110 mm | 240 mm | 50 mm |
| 7924A5 | 25 | 120 mm | 165 mm | 22 mm |
| 7924C | 15 | 120 mm | 165 mm | 22 mm |
| 7024A | 30 | 120 mm | 180 mm | 28 mm |
| 7224A | 30 | 120 mm | 215 mm | 40 mm |
| 7224B | 40 | 120 mm | 215 mm | 40 mm |
| 7224BEAT85 | 40 | 120 mm | 215 mm | 40 mm |
| 7324A | 30 | 120 mm | 260 mm | 55 mm |
| 7324B | 40 | 120 mm | 260 mm | 55 mm |
| 7324BEAT85 | 40 | 120 mm | 260 mm | 55 mm |
Double Row
| Part Number | Seal Type | Contact Angle (Degree) | Bore Dia (d) | Outer Dia (D) | Width (B) |
| 5200 | Open | 30 º | 10 mm | 30 mm | 14.3 mm |
| 5200 ZZ | Shielded | 30 º | 10 mm | 30 mm | 14.3 mm |
| 5200 DDU | Sealed | 30 º | 10 mm | 30 mm | 14.3 mm |
| 5201 | Open | 30 º | 12 mm | 32 mm | 15.9 mm |
| 5201 ZZ | Shielded | 30 º | 12 mm | 32 mm | 15.9 mm |
| 5201 DDU | Sealed | 30 º | 12 mm | 32 mm | 15.9 mm |
| 5202 | Open | 30 º | 15 mm | 35 mm | 15.9 mm |
| 5202 ZZ | Shielded | 30 º | 15 mm | 35 mm | 15.9 mm |
| 5202 DDU | Sealed | 30 º | 15 mm | 35 mm | 15.9 mm |
| 5302 | Open | 30 º | 15 mm | 42 mm | 19 mm |
| 5302 ZZ | Shielded | 30 º | 15 mm | 42 mm | 19 mm |
| 5302 DDU | Sealed | 30 º | 15 mm | 42 mm | 19 mm |
| 5203 | Open | 30 º | 17 mm | 40 mm | 17.5 mm |
| 5203 ZZ | Shielded | 30 º | 17 mm | 40 mm | 17.5 mm |
| 5203 DDU | Sealed | 30 º | 17 mm | 40 mm | 17.5 mm |
| 5303 | Open | 30 º | 17 mm | 47 mm | 22.2 mm |
| 5303 ZZ | Shielded | 30 º | 17 mm | 47 mm | 22.2 mm |
| 5303 DDU | Sealed | 30 º | 17 mm | 47 mm | 22.2 mm |
| 5204 | Open | 30 º | 20 mm | 47 mm | 20.6 mm |
| 5204 ZZ | Shielded | 30 º | 20 mm | 47 mm | 20.6 mm |
| 5204 DDU | Sealed | 30 º | 20 mm | 47 mm | 20.6 mm |
| 5304 | Open | 30 º | 20 mm | 52 mm | 22.2 mm |
| 5304 DDU | Sealed | 30 º | 20 mm | 52 mm | 22.2 mm |
| 5304 ZZ | Shielded | 30 º | 20 mm | 52 mm | 22.2 mm |
| 5205 | Open | 30 º | 25 mm | 52 mm | 20.6 mm |
| 5205 ZZ | Shielded | 30 º | 25 mm | 52 mm | 20.6 mm |
| 5205 DDU | Sealed | 30 º | 25 mm | 52 mm | 20.6 mm |
| 5305 | Open | 30 º | 25 mm | 62 mm | 25.4 mm |
| 5305 ZZ | Shielded | 30 º | 25 mm | 62 mm | 25.4 mm |
| 5305 DDU | Sealed | 30 º | 25 mm | 62 mm | 25.4 mm |
| 5206 DDU | Sealed | 30 º | 30 mm | 62 mm | 23.8 mm |
| 5206 ZZ | Shielded | 30 º | 30 mm | 62 mm | 23.8 mm |
| 5206 | Open | 30 º | 30 mm | 62 mm | 23.8 mm |
| 5306 | Open | 30 º | 30 mm | 72 mm | 30.2 mm |
| 5306 ZZ | Shielded | 30 º | 30 mm | 72 mm | 30.2 mm |
| 5306 DDU | Sealed | 30 º | 30 mm | 72 mm | 30.2 mm |
| 5207 ZZ | Shielded | 30 º | 35 mm | 72 mm | 27 mm |
| 5207 | Open | 30 º | 35 mm | 72 mm | 27 mm |
| 5207 DDU | Sealed | 30 º | 35 mm | 72 mm | 27 mm |
| 5307 ZZ | Shielded | 30 º | 35 mm | 80 mm | 34.9 mm |
| 5307 | Open | 30 º | 35 mm | 80 mm | 34.9 mm |
| 5307 DDU | Sealed | 30 º | 35 mm | 80 mm | 34.9 mm |
| 5208 DDU | Sealed | 30 º | 40 mm | 80 mm | 30.2 mm |
| 5208 | Open | 30 º | 40 mm | 80 mm | 30.2 mm |
| 5208 ZZ | Shielded | 30 º | 40 mm | 80 mm | 30.2 mm |
| 5308 | Open | 30 º | 40 mm | 90 mm | 36.5 mm |
| 5308 ZZ | Shielded | 30 º | 40 mm | 90 mm | 36.5 mm |
| 5308 DDU | Sealed | 30 º | 40 mm | 90 mm | 36.5 mm |
| 5209 | Open | 30 º | 45 mm | 85 mm | 30.2 mm |
| 5209 ZZ | Shielded | 30 º | 45 mm | 85 mm | 30.2 mm |
| 5209 DDU | Sealed | 30 º | 45 mm | 85 mm | 30.2 mm |
| 5309 ZZ | Shielded | 30 º | 45 mm | 100 mm | 39.7 mm |
| 5309 | Open | 30 º | 45 mm | 100 mm | 39.7 mm |
| 5309 DDU | Sealed | 30 º | 45 mm | 100 mm | 39.7 mm |
| 5210 DDU | Sealed | 30 º | 50 mm | 90 mm | 30.2 mm |
| 5210 | Open | 30 º | 50 mm | 90 mm | 30.2 mm |
| 5210 ZZ | Shielded | 30 º | 50 mm | 90 mm | 30.2 mm |
| 5310 | Open | 30 º | 50 mm | 110 mm | 44.4 mm |
| 5310 ZZ | Shielded | 30 º | 50 mm | 110 mm | 44.4 mm |
| 5310 DDU | Sealed | 30 º | 50 mm | 110 mm | 44.4 mm |
| 5211 ZZ | Shielded | 30 º | 55 mm | 100 mm | 33.3 mm |
| 5211 | Open | 30 º | 55 mm | 100 mm | 33.3 mm |
| 5211 DDU | Sealed | 30 º | 55 mm | 100 mm | 33.3 mm |
| 5311 | Open | 30 º | 55 mm | 120 mm | 49.2 mm |
| 5311 ZZ | Shielded | 30 º | 55 mm | 120 mm | 49.2 mm |
| 5311 DDU | Sealed | 30 º | 55 mm | 120 mm | 49.2 mm |
| 5212 ZZ | Shielded | 30 º | 60 mm | 110 mm | 36.5 mm |
| 5212 | Open | 30 º | 60 mm | 110 mm | 36.5 mm |
| 5212 DDU | Sealed | 30 º | 60 mm | 110 mm | 36.5 mm |
| 5312 | Open | 30 º | 60 mm | 130 mm | 54 mm |
| 5312 ZZ | Shielded | 30 º | 60 mm | 130 mm | 54 mm |
| 5312 DDU | Sealed | 30 º | 60 mm | 130 mm | 54 mm |
| 5213 | Open | 30 º | 65 mm | 120 mm | 38.1 mm |
| 5213 ZZ | Shielded | 30 º | 65 mm | 120 mm | 38.1 mm |
| 5213 DDU | Sealed | 30 º | 65 mm | 120 mm | 38.1 mm |
| 5313 ZZ | Shielded | 30 º | 65 mm | 140 mm | 58.7 mm |
| 5313 | Open | 30 º | 65 mm | 140 mm | 58.7 mm |
| 5313 DDU | Sealed | 30 º | 65 mm | 140 mm | 58.7 mm |
| 5214 | Open | 30 º | 70 mm | 125 mm | 39.7 mm |
| 5214 ZZ | Shielded | 30 º | 70 mm | 125 mm | 39.7 mm |
| 5214 DDU | Sealed | 30 º | 70 mm | 125 mm | 39.7 mm |
| 5314 | Open | 30 º | 70 mm | 150 mm | 63.5 mm |
| 5314 ZZ | Shielded | 30 º | 70 mm | 150 mm | 63.5 mm |
| 5314 DDU | Sealed | 30 º | 70 mm | 150 mm | 63.5 mm |
| 5215 DDU | Sealed | 30 º | 75 mm | 130 mm | 41.3 mm |
| 5215 ZZ | Shielded | 30 º | 75 mm | 130 mm | 41.3 mm |
| 5215 | Open | 30 º | 75 mm | 130 mm | 41.3 mm |
| 5216 | Open | 30 º | 80 mm | 140 mm | 44.4 mm |
| 5216 DDU | Sealed | 30 º | 80 mm | 140 mm | 44.4 mm |
| 5216 ZZ | Shielded | 30 º | 80 mm | 140 mm | 44.4 mm |
| 5217 | Open | 30 º | 85 mm | 150 mm | 49.2 mm |
| 5217 ZZ | Shielded | 30 º | 85 mm | 150 mm | 49.2 mm |
| 5217 DDU | Sealed | 30 º | 85 mm | 150 mm | 49.2 mm |
Four-point Angular Contact Series
Four-point contact bearings are single-row angular contact ball bearings and therefore require significantly less space in an axial direction than double-row designs.
| Part Number | Bore Dia (d) | Outer Dia (D) | Width (B) |
| QJ306 | 30 mm | 72 mm | 19 mm |
| QJ206 | 30 mm | 62 mm | 16 mm |
| QJ207 | 35 mm | 72 mm | 17 mm |
| QJ307 | 35 mm | 80 mm | 21 mm |
| QJ208 | 40 mm | 80 mm | 18 mm |
| QJ308 | 40 mm | 90 mm | 23 mm |
| QJ209 | 45 mm | 85 mm | 19 mm |
| QJ309 | 45 mm | 100 mm | 25 mm |
| QJ210 | 50 mm | 90 mm | 20 mm |
| QJ310 | 50 mm | 110 mm | 27 mm |
| QJ211 | 55 mm | 100 mm | 21 mm |
| QJ311 | 55 mm | 120 mm | 29 mm |
| QJ212 | 60 mm | 110 mm | 22 mm |
| QJ312 | 60 mm | 130 mm | 31 mm |
| QJ213 | 65 mm | 120 mm | 23 mm |
| QJ313 | 65 mm | 140 mm | 33 mm |
| QJ214 | 70 mm | 125 mm | 24 mm |
| QJ314 | 70 mm | 150 mm | 35 mm |
| QJ215 | 75 mm | 130 mm | 25 mm |
| QJ315 | 75 mm | 160 mm | 37 mm |
| QJ316 | 80 mm | 170 mm | 39 mm |
| QJ1016 | 80 mm | 125 mm | 22 mm |
| QJ216 | 80 mm | 140 mm | 26 mm |
| QJ1017 | 85 mm | 130 mm | 22 mm |
| QJ217 | 85 mm | 150 mm | 28 mm |
| QJ317 | 85 mm | 180 mm | 41 mm |
| QJ1018 | 90 mm | 140 mm | 24 mm |
| QJ318 | 90 mm | 190 mm | 43 mm |
| QJ218 | 90 mm | 160 mm | 30 mm |
| QJ1019 | 95 mm | 145 mm | 24 mm |
| QJ219 | 95 mm | 170 mm | 32 mm |
| QJ319 | 95 mm | 200 mm | 45 mm |
| QJ1020 | 100 mm | 150 mm | 24 mm |
| QJ320 | 100 mm | 215 mm | 47 mm |
| QJ220 | 100 mm | 180 mm | 34 mm |
| QJ221 | 105 mm | 190 mm | 36 mm |
| QJ1021 | 105 mm | 160 mm | 26 mm |
| QJ321 | 105 mm | 225 mm | 49 mm |
| QJ1022 | 110 mm | 170 mm | 28 mm |
| QJ222 | 110 mm | 200 mm | 38 mm |
| QJ322 | 110 mm | 240 mm | 50 mm |
| QJ1024 | 120 mm | 180 mm | 28 mm |
| QJ224 | 120 mm | 215 mm | 40 mm |
| QJ324 | 120 mm | 260 mm | 55 mm |
| QJ1026 | 130 mm | 200 mm | 33 mm |
| QJ226 | 130 mm | 230 mm | 40 mm |
| QJ326 | 130 mm | 280 mm | 58 mm |
| QJ1028 | 140 mm | 210 mm | 33 mm |
| QJ228 | 140 mm | 250 mm | 42 mm |
| QJ328 | 140 mm | 300 mm | 62 mm |
| QJ1030 | 150 mm | 225 mm | 35 mm |
| QJ230 | 150 mm | 270 mm | 45 mm |
| QJ330 | 150 mm | 320 mm | 65 mm |
| QJ1032 | 160 mm | 240 mm | 38 mm |
| QJ232 | 160 mm | 290 mm | 48 mm |
| QJ332 | 160 mm | 340 mm | 68 mm |
| QJ1034 | 170 mm | 260 mm | 42 mm |
| QJ234 | 170 mm | 310 mm | 52 mm |
| QJ334 | 170 mm | 360 mm | 72 mm |
| QJ1036 | 180 mm | 280 mm | 46 mm |
| QJ236 | 180 mm | 320 mm | 52 mm |
| QJ336 | 180 mm | 380 mm | 75 mm |
| QJ1038 | 190 mm | 290 mm | 46 mm |
| QJ238 | 190 mm | 340 mm | 55 mm |
| QJ338 | 190 mm | 400 mm | 78 mm |
| QJ240 | 200 mm | 360 mm | 58 mm |
| QJ340 | 200 mm | 420 mm | 80 mm |
| QJ1040 | 200 mm | 310 mm | 51 mm |
Precision Series for Machine Tools
| Part Number | NSK Code | Arrangement | Contact Angle (Degree) | Bore Dia (d) | Outer Dia (D) |
| 706 CD/P4A | 706CTRP4 | DB DF DT DG | 15 | 6 mm | 17 mm |
| 707 CD/P4A | 707CTRP4 | DB DF DT DG | 15 | 7 mm | 19 mm |
| 727 CD/P4A | 727CTRP4 | DB DF DT DG | 15 | 7 mm | 22 mm |
| 719/8 CE/P4A | 798CTRP4 | DB DF DT DG | 15 | 8 mm | 19 mm |
| 708 CD/P4A | 708CTRP4 | DB DF DT DG | 15 | 8 mm | 22 mm |
| 728 CD/P4A | 728CTRP4 | DB DF DT DG | 15 | 8 mm | 24 mm |
| 719/9 CE/P4A | 799CTRP4 | DB DF DT DG | 15 | 9 mm | 20 mm |
| 709 CD/P4A | 709CTRP4 | DB DF DT DG | 15 | 9 mm | 24 mm |
| 729 CD/P4A | 729CTRP4 | DB DF DT DG | 15 | 9 mm | 26 mm |
| 71800 CD/P4 | 7800CTRP4 | DB DF DT DG | 15 | 10 mm | 19 mm |
| 71900 CD/P4A | 7900CTRP4 | DB DF DT DG | 15 | 10 mm | 22 mm |
| 7000 CD/P4A | 7000CTRP4 | DB DF DT DG | 15 | 10 mm | 26 mm |
| 7200 CD/P4A | 7200CTRP4 | DB DF DT DG | 15 | 10 mm | 30 mm |
| 71801 CD/P4 | 7801CTRP4 | DB DF DT DG | 15 | 12 mm | 21 mm |
| 71901 CD/P4A | 7901CTRP4 | DB DF DT DG | 15 | 12 mm | 24 mm |
| 7001 CD/P4A | 7001CTRP4 | DB DF DT DG | 15 | 12 mm | 28 mm |
| 7201 CD/P4A | 7201CTRP4 | DB DF DT DG | 15 | 12 mm | 32 mm |
| 71802 CD/P4 | 7802CTRP4 | DB DF DT DG | 15 | 15 mm | 24 mm |
| 71902 CD/P4A | 7902CTRP4 | DB DF DT DG | 15 | 15 mm | 28 mm |
| 7002 CD/P4A | 7002CTRP4 | DB DF DT DG | 15 | 15 mm | 32 mm |
| 7202 CD/P4A | 7202CTRP4 | DB DF DT DG | 15 | 15 mm | 35 mm |
| 71803 CD/P4 | 7803CTRP4 | DB DF DT DG | 15 | 17 mm | 26 mm |
| 71903 CD/P4A | 7903CTRP4 | DB DF DT DG | 15 | 17 mm | 30 mm |
| 71903 CE/P4A | 7903CTRP4 | DB DF DT DG | 15 | 17 mm | 30 mm |
| 7003 CD/P4A | 7003CTRP4 | DB DF DT DG | 15 | 17 mm | 35 mm |
| 7203 CD/P4A | 7203CTRP4 | DB DF DT DG | 15 | 17 mm | 40 mm |
| 71804 CD/P4 | 7804CTRP4 | DB DF DT DG | 15 | 20 mm | 32 mm |
| 71904 CD/P4A | 7904CTRP4 | DB DF DT DG | 15 | 20 mm | 37 mm |
| 7004 CD/P4A | 7004CTRP4 | DB DF DT DG | 15 | 20 mm | 42 mm |
| 7204 CD/P4A | 7204CTRP4 | DB DF DT DG | 15 | 20 mm | 47 mm |
| 71805 CD/P4 | 7805CTRP4 | DB DF DT DG | 15 | 25 mm | 37 mm |
| 71905 CD/P4A | 7905CTRP4 | DB DF DT DG | 15 | 25 mm | 42 mm |
| 7005 CD/P4A | 7005CTRP4 | DB DF DT DG | 15 | 25 mm | 47 mm |
| 7205 CD/P4A | 7205CTRP4 | DB DF DT DG | 15 | 25 mm | 52 mm |
| 71806 CD/P4 | 7806CTRP4 | DB DF DT DG | 15 | 30 mm | 42 mm |
| 71906 CD/P4A | 7906CTRP4 | DB DF DT DG | 15 | 30 mm | 47 mm |
| 7006 CD/P4A | 7006CTRP4 | DB DF DT DG | 15 | 30 mm | 55 mm |
| 7206 CD/P4A | 7206CTRP4 | DB DF DT DG | 15 | 30 mm | 62 mm |
| 71807 CD/P4 | 7807CTRP4 | DB DF DT DG | 15 | 35 mm | 47 mm |
| 71907 CD/P4A | 7907CTRP4 | DB DF DT DG | 15 | 35 mm | 55 mm |
| 7007 CD/P4A | 7007CTRP4 | DB DF DT DG | 15 | 35 mm | 62 mm |
| 7207 CD/P4A | 7207CTRP4 | DB DF DT DG | 15 | 35 mm | 72 mm |
| 71808 CD/P4 | 7808CTRP4 | DB DF DT DG | 15 | 40 mm | 52 mm |
| 71908 CD/P4A | 7908CTRP4 | DB DF DT DG | 15 | 40 mm | 62 mm |
| 7008 CD/P4A | 7008CTRP4 | DB DF DT DG | 15 | 40 mm | 68 mm |
| 7208 CD/P4A | 7208CTRP4 | DB DF DT DG | 15 | 40 mm | 80 mm |
| 71809 CD/P4 | 7809CTRP4 | DB DF DT DG | 15 | 45 mm | 58 mm |
| 71909 CD/P4A | 7909CTRP4 | DB DF DT DG | 15 | 45 mm | 68 mm |
| 7009 CD/P4A | 7009CTRP4 | DB DF DT DG | 15 | 45 mm | 75 mm |
| 7209 CD/P4A | 7209CTRP4 | DB DF DT DG | 15 | 45 mm | 85 mm |
| 71810 CD/P4 | 7810CTRP4 | DB DF DT DG | 15 | 50 mm | 65 mm |
| 71910 CD/P4A | 7910CTRP4 | DB DF DT DG | 15 | 50 mm | 72 mm |
| 7010 CD/P4A | 7010CTRP4 | DB DF DT DG | 15 | 50 mm | 80 mm |
| 7210 CD/P4A | 7210CTRP4 | DB DF DT DG | 15 | 50 mm | 90 mm |
| 71811 CD/P4 | 7811CTRP4 | DB DF DT DG | 15 | 55 mm | 72 mm |
| 71911 CD/P4A | 7911CTRP4 | DB DF DT DG | 15 | 55 mm | 80 mm |
| 7011 CD/P4A | 7011CTRP4 | DB DF DT DG | 15 | 55 mm | 90 mm |
| 7211 CD/P4A | 7211CTRP4 | DB DF DT DG | 15 | 55 mm | 100 mm |
| 71812 CD/P4 | 7812CTRP4 | DB DF DT DG | 15 | 60 mm | 78 mm |
| 71912 CD/P4A | 7912CTRP4 | DB DF DT DG | 15 | 60 mm | 85 mm |
| 7012 CD/P4A | 7012CTRP4 | DB DF DT DG | 15 | 60 mm | 95 mm |
| 7212 CD/P4A | 7212CTRP4 | DB DF DT DG | 15 | 60 mm | 110 mm |
| 71813 CD/P4 | 7813CTRP4 | DB DF DT DG | 15 | 65 mm | 85 mm |
| 71913 CD/P4A | 7913CTRP4 | DB DF DT DG | 15 | 65 mm | 90 mm |
| 7013 CD/P4A | 7013CTRP4 | DB DF DT DG | 15 | 65 mm | 100 mm |
| 7213 CD/P4A | 7213CTRP4 | DB DF DT DG | 15 | 65 mm | 120 mm |
| 71814 CD/P4 | 7814CTRP4 | DB DF DT DG | 15 | 70 mm | 90 mm |
| 71914 CD/P4A | 7914CTRP4 | DB DF DT DG | 15 | 70 mm | 100 mm |
| 7014 CD/P4A | 7014CTRP4 | DB DF DT DG | 15 | 70 mm | 110 mm |
| 7214 CD/P4A | 7214CTRP4 | DB DF DT DG | 15 | 70 mm | 125 mm |
| 71815 CD/P4 | 7815CTRP4 | DB DF DT DG | 15 | 75 mm | 95 mm |
| 71915 CD/P4A | 7915CTRP4 | DB DF DT DG | 15 | 75 mm | 105 mm |
| 7015 CD/P4A | 7015CTRP4 | DB DF DT DG | 15 | 75 mm | 115 mm |
| 7215 CD/P4A | 7215CTRP4 | DB DF DT DG | 15 | 75 mm | 130 mm |
| 71816 CD/P4 | 7816CTRP4 | DB DF DT DG | 15 | 80 mm | 100 mm |
| 71916 CD/P4A | 7916CTRP4 | DB DF DT DG | 15 | 80 mm | 110 mm |
| 7016 CD/P4A | 7016CTRP4 | DB DF DT DG | 15 | 80 mm | 125 mm |
| 7216 CD/P4A | 7216CTRP4 | DB DF DT DG | 15 | 80 mm | 140 mm |
| 71817 CD/P4 | 7817CTRP4 | DB DF DT DG | 15 | 85 mm | 110 mm |
| 71917 CD/P4A | 7917CTRP4 | DB DF DT DG | 15 | 85 mm | 120 mm |
| 7017 CD/P4A | 7017CTRP4 | DB DF DT DG | 15 | 85 mm | 130 mm |
| 7217 CD/P4A | 7217CTRP4 | DB DF DT DG | 15 | 85 mm | 150 mm |
| 71818 CD/P4 | 7818CTRP4 | DB DF DT DG | 15 | 90 mm | 115 mm |
| 71918 CD/P4A | 7918CTRP4 | DB DF DT DG | 15 | 90 mm | 125 mm |
| 71918 CE/P4A | 7918CTRP4 | DB DF DT DG | 15 | 90 mm | 125 mm |
| 7018 CD/P4A | 7018CTRP4 | DB DF DT DG | 15 | 90 mm | 140 mm |
| 7218 CD/P4A | 7218CTRP4 | DB DF DT DG | 15 | 90 mm | 160 mm |
| 71819 CD/P4 | 7819CTRP4 | DB DF DT DG | 15 | 95 mm | 120 mm |
| 71919 CD/P4A | 7919CTRP4 | DB DF DT DG | 15 | 95 mm | 130 mm |
| 7019 CB/P4A | 7019CTRP4 | DB DF DT DG | 15 | 95 mm | 145 mm |
| 7019 CD/P4A | 7019CTRP4 | DB DF DT DG | 15 | 95 mm | 145 mm |
| 7219 CD/P4A | 7219CTRP4 | DB DF DT DG | 15 | 95 mm | 170 mm |
| 71820 CD/P4 | 7820CTRP4 | DB DF DT DG | 15 | 100 mm | 125 mm |
| 71920 CB/P4A | 7920CTRP4 | DB DF DT DG | 15 | 100 mm | 140 mm |
| Part Number | Arrangement | Seal Type | Bore Dia (d) | Outer Dia (D) | Width (B) |
| 15TAC47C | SU | Open | 15 mm | 47 mm | 15 mm |
| 17TAC47C | SU | Open | 17 mm | 47 mm | 15 mm |
| 20TAC47C | SU | Open | 20 mm | 47 mm | 15 mm |
| 25TAC62C | SU | Open | 25 mm | 62 mm | 15 mm |
| 30TAC62C | SU | Open | 30 mm | 62 mm | 15 mm |
| 35TAC72C | SU | Open | 35 mm | 72 mm | 15 mm |
| 40TAC72C | SU | Open | 40 mm | 72 mm | 15 mm |
| 40TAC90C | SU | Open | 40 mm | 90 mm | 20 mm |
| 45TAC75C | SU | Open | 45 mm | 75 mm | 15 mm |
| 45TAC100C | SU | Open | 45 mm | 100 mm | 20 mm |
| 50TAC100C | SU | Open | 50 mm | 100 mm | 20 mm |
| 55TAC100C | SU | Open | 55 mm | 100 mm | 20 mm |
| 55TAC120C | SU | Open | 55 mm | 120 mm | 20 mm |
| 60TAC120C | SU | Open | 60 mm | 120 mm | 20 mm |
| Part Number | Arrangement | Contact Angle (Degree) | Bore Dia (d) | Outer Dia (D) | Width (B) |
| 50BAR10E | DB | 30 | 50 mm | 80 mm | 28.5 mm |
| 50BTR10E | DB | 40 | 50 mm | 80 mm | 28.5 mm |
| 55BAR10E | DB | 30 | 55 mm | 90 mm | 33 mm |
| 55BTR10E | DB | 40 | 55 mm | 90 mm | 33 mm |
| 60BAR10E | DB | 30 | 60 mm | 95 mm | 33 mm |
| 60BTR10E | DB | 40 | 60 mm | 95 mm | 33 mm |
| 65BAR10E | DB | 30 | 65 mm | 100 mm | 33 mm |
| 65BTR10E | DB | 40 | 65 mm | 100 mm | 33 mm |
| 70BAR10E | DB | 30 | 70 mm | 110 mm | 36 mm |
| 70BTR10E | DB | 40 | 70 mm | 110 mm | 36 mm |
| 75BAR10E | DB | 30 | 75 mm | 115 mm | 36 mm |
| 75BTR10E | DB | 40 | 75 mm | 115 mm | 36 mm |
| 80BAR10E | DB | 30 | 80 mm | 125 mm | 40.5 mm |
| 80BTR10E | DB | 40 | 80 mm | 125 mm | 40.5 mm |
| 85BAR10E | DB | 30 | 85 mm | 130 mm | 40.5 mm |
| 85BTR10E | DB | 40 | 85 mm | 130 mm | 40.5 mm |
| 90BAR10E | DB | 30 | 90 mm | 140 mm | 45 mm |
| 90BTR10E | DB | 40 | 90 mm | 140 mm | 45 mm |
| 95BAR10E | DB | 30 | 95 mm | 145 mm | 45 mm |
| 95BTR10E | DB | 40 | 95 mm | 145 mm | 45 mm |
| 100BAR10E | DB | 30 | 100 mm | 150 mm | 45 mm |
| 100BTR10E | DB | 40 | 100 mm | 150 mm | 45 mm |
| 105BAR10E | DB | 30 | 105 mm | 160 mm | 49.5 mm |
| 105BTR10E | DB | 40 | 105 mm | 160 mm | 49.5 mm |
| 110BAR10E | DB | 30 | 110 mm | 170 mm | 54 mm |
| 110BTR10E | DB | 40 | 110 mm | 170 mm | 54 mm |
| 120BAR10E | DB | 30 | 120 mm | 180 mm | 54 mm |
| 120BTR10E | DB | 40 | 120 mm | 180 mm | 54 mm |
| 130BAR10E | DB | 30 | 130 mm | 200 mm | 63 mm |
| 130BTR10E | DB | 40 | 130 mm | 200 mm | 63 mm |
| 140BAR10E | DB | 30 | 140 mm | 210 mm | 63 mm |
| 140BTR10E | DB | 40 | 140 mm | 210 mm | 63 mm |
| 150BAR10S | DB | 30 | 150 mm | 225 mm | 67.5 mm |
| 150BTR10S | DB | 40 | 150 mm | 225 mm | 67.5 mm |
| 160BAR10S | DB | 30 | 160 mm | 240 mm | 72 mm |
| 160BTR10S | DB | 40 | 160 mm | 240 mm | 72 mm |
| 170BAR10S | DB | 30 | 170 mm | 260 mm | 81 mm |
| 170BTR10S | DB | 40 | 170 mm | 260 mm | 81 mm |
| 180BAR10S | DB | 30 | 180 mm | 280 mm | 90 mm |
| 180BTR10S | DB | 40 | 180 mm | 280 mm | 90 mm |
| 190BAR10S | DB | 30 | 190 mm | 290 mm | 90 mm |
| 190BTR10S | DB | 40 | 190 mm | 290 mm | 90 mm |
| 200BAR10S | DB | 30 | 200 mm | 310 mm | 99 mm |
| 200BTR10S | DB | 40 | 200 mm | 310 mm | 99 mm |
| 220BAR10S | DB | 30 | 220 mm | 340 mm | 108 mm |
| 220BTR10S | DB | 40 | 220 mm | 340 mm | 108 mm |
| 240BAR10S | DB | 30 | 240 mm | 360 mm | 108 mm |
| 240BTR10S | DB | 40 | 240 mm | 360 mm | 108 mm |
| 260BAR10S | DB | 30 | 260 mm | 400 mm | 123 mm |
| 260BTR10S | DB | 40 | 260 mm | 400 mm | 123 mm |
| 300BAR10S | DB | 30 | 300 mm | 460 mm | 142.5 mm |
Symbol Explanation
| Suffix | |
| A | Single row bearing, 30° contact angle |
| A | Double row bearing, no illing slots |
| AB | Single row inch bearing, 20° contact angle |
| AC | Single row bearing, 25° contact angle |
| B | Single row bearing, 40° contact angle |
| D | Two-piece inner ring |
| E | Optimized internal design |
| N | Snap ring groove in the outer ring |
| NR | Snap ring groove in the outer ring, with appropriate snap ring |
| N1 | One locating slot (notch) in one outer ring side face |
| N2 | Two locating slots (notches) in one outer ring side face, 180° apart |
| CB | Double row bearing, controlled axial internal clearance |
| CA | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have axial internal clearance smaller than Normal (CB) |
| CB | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have Normal axial internal clearance |
| CC | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have axial internal clearance greater than Normal (CB) |
| G | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have axial internal clearance |
| GA | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have light preload |
| GB | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have moderate preload |
| GC | Bearing for universal matching Two bearings arranged back-to-back or face-to-face have heavy preload |
| 2RS1 | Contact seal, NBR, on both sides |
| 2RZ | Non-contact seal, NBR, on both sides |
| 2Z | Shield on both sides |
| / | Stamped steel cage, ball centred (double row bearing) |
| F | Machined steel cage, ball centred |
| FA | Machined steel cage, outer ring centred |
| J | Stamped steel cage, ball centred (single row bearing) |
| J1 | Stamped steel cage, ball centred (double row bearing with a two-piece inner ring) |
| M | Machined brass cage, ball centred; different designs are identiied by a number following the M |
| MA | Machined brass cage, outer ring centred |
| MB | Machined brass cage, inner ring centred |
| P | Glass ibre reinforced PA66 cage, ball centred |
| PH | Glass ibre reinforced PEEK cage, ball centred |
| TN9 | Glass ibre reinforced PA66 cage, ball centred |
| Y | Stamped brass cage, ball centred |
| S1 | Bearing rings heat stabilized for operating temperatures ≤ 200 °C |
| DB | Back-to-back |
| DF | Face-to-face |
| DT | Two bearings matched for mounting in tandem |
| P62 | P6 + C2 |
| P63 | P6 + C3 |
| P64 | P6 + C4 |
| MT33 | Grease |
